5MP Thermal Bullet Camera,
8mm (37°) Optical Lens,
7mm (26°) Themal Lens, 20M IR White LED

KEY FEATURES

Resolution: 2592x1944/ 25/30FPS (5MP).
Lens: 8mm (37°) Optical.
Lens: 7mm (26°) Thermal.
Thermal.
Active Deterrence.
IR Range: 20m (2 IR LED Array).
H.265+/H.264+/H.265/H.264 Compression.
General Analytics: Camera Tampering.
AI Analytics: Line Crossing, Sterile Area.
True WDR (120dB), BLC, HLC, ROI.
PoE.
SD Card Support (Up to 256GB).
Built-in Microphone + Audio Input.
ONVIF.
IP66.
Weight: 750g.
Power: DC12V/~750mA / PoE/~9W.

FUNCTIONS

This 2MP Turret/Dome camera is equipped with a built-in warm LED light source, F1.0 super-wide aperture lens, and state-of-the-art sensor.
When the ambient light is insufficient, the camera will turn on its integral lighting that will allow it to continue to provide a full color image.
Crimes such as theft, drug violations, simple assaults, robbery, or vandalism are known to be more likely to occur at night: This Provision-ISR’s
Rainbow camera can provide authorities with crucial information, such as people’s clothes or car’s color.

Idealisk för temperaturkontroll

SPECIFICATIONS
Video (Thermal)
Detector Type	12µm Vanadium oxide uncooled focal plane detector
Resolution	256×192
Spectral Range	8µm-14µm
Thermal Sensitivity (NETD)	≤50mK(@25°C, F#=1.0)
Color Sets	Black hot, White hot, Rainbow, iron oxide red, Lava
Temperature Detection Distance	7.7m (Target size is 0.1m * 0.1m)
Fire Detection Distance	24m (Flame size is 0.1m * 0.1m)
DRI Distance Human	Detection: 292m(958ft) Recognition: 73m(240ft) Identification: 36m(118ft)
DRI Distance Vehicle	Detection: 894m (2933ft) Recognition: 224m(735ft) Identification: 112m(367ft)
Video (Optical)
Electronic Shutter	1/23s ~ 1/100000s
Frame Rate	1-25/30FPS
Day & Night	ICR
Min. Illumination	Day: 0.1lux Night: 0.03lux (@F1.6, AGC on) 0lux with IR on
Audio
Audio compression	G.711A/G.711U
Communication	2-Way Audio
Image Settings	AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable, Lens distortion correction
Image Enhancement	True WDR (120dB), BLC, HLC, ROI
Noise Reduction	3D-DNR
Image Orientation	Mirror/Flip
Privacy Zone	Yes
Motion Detection	Yes
Analytics	General Alanlytics: Camera Tampering AI (Optical Image): DDA Sterile Area, DDA Line Crossing, DDA Object Counting, Face Detection (10 Faces per frame) AI (Thermal): DDA Sterile Area, DDA Line Crossing
Video Compression	H.265/H.264/MJPEG
Resolution	5MP/4MP/2K/3MP/2MP/1MP/D1/QVGA/CIF/QCIF
Multi-Stream	Master Stream: 5MP(2592x1944)/4MP(2592x1520)/2K(2560x1440)/3MP/2MP/1MP Substream: 1MP/D1/CIF/QCIF Third Stream: D1/CIF/QCIF(1~30fps) Thermal Stream: 1MP/D1/CIF/QCIF
Bit rate	64Kbps ~ 11Mbps@H.265 / 64Kbps ~ 11Mbps@H.264
Encode Mode	VBR/CBR
Image Quality	Five levels under VBR; Free adjustment under CBR
Bracket	3-Axis Bracket
IR Distance	20m (2 High-Power IR LED) White Strobe light
Lens (Field of View)	Optical: 4mm (80°) Thermal: 3mm (60°)
Iris	Fixed Iriss
Lens Mount	Ø14 Mount
Protection Rate	Water Proof: IP66
Weight(gross)	~700g
Network	RJ45(+PoE)
Power	PoE/DC Socket
Analog Video Output	No
Audio Connectivity	Built-in speaker + Audio input
SD Card	Event/Schedule based Main/Substream recording (Up to 256Gb)
Hard Reset Button	Yes
Alarm	Alarm in + Alarm out
Remote Monitoring	IE Browsing, Ossia VMS Software, Provision Cam2 Mobile App
User Access	Supports simultaneous monitoring of up to 10 users with multi-stream real-time transmission
Network Protocol	IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS, P2P
ONVIF	Yes
Ethernet	100Mbps
PoE	Yes
Power Supply	DC12V/~750mA / PoE/~9W
Work Environment	-30°C~60°C, 10%~90% Humidity
