KEY FEATURES

Video and audio channels: 4.
Supported protocols: ONVIF, RTSP.
Recording speed up to 120fps at 1920x1080.
Supports resolution up to 1920x1080.
Recorded stream size: 20Mb/s in total from all cameras.
Internal HDDs mount: 1.
Monitor outputs: 2 (HDMI, VGA).

COMPATIBILITY

FUNCTIONS

VIDEO
Maximum Supported Camera Resolution	1920x1080
Compression	H.264, MJPEG, H.264+
Monitor Output	Main (split screen, full screen, sequence): 1xHDMI, 1xVGA (up to 2 monitors simultaneously)
Dualstreaming Support	Yes*
AUDIO
Audio Output	1xline-out (RCA)
RECORDING
Recording Speed	120fps (4x30fps for 1280x720), 120fps (4x30fps for 1920x1080)
Stream Size	20Mb/s in total from all cameras
Recording Mode	Time-lapse, triggered by: manual, motion detection
Schedule	Individual settings for: each camera, each day of the week, configuration with an accuracy of: 60 min, possibility of combining individual recording modes
Prealarm/Postalarm	Up to 30s/up to 600 s
DISPLAY
Display Speed	120fps (4x30fps)**
PLAYBACK
Playback Speed	120fps (4x30fps for 1280x720), 30fps (1x30fps for 1920x1080)
Recorded Data Search	By date/time
BACKUP
Backup Methods	USB port (HDD or Flash memory), network
Backup File Format	AVI
STORAGE
Internal Storage	Available mount: 1xHDD 3.5” 4 TB SATA
Total Internal Capacity	4TB
ALARM
Camera Alarm Input/Output	Supports camera’s alarm input/output *
Motion Detection	Supports camera’s motion detection*
System Reaction to Alarm Events	Buzzer, e-mail, screen message, recording activation, PTZ
NETWORK
Network Interface	1xEthernet - RJ-45 interface, 10/100Mbit/s
Network Protocols Support	HTTP, TCP/IP, IPv4, UDP, FTP, DHCP, DNS, DDNS, NTP, RTSP, UPnP, SMTP
ONVIF Protocol Support	Profile S (ONVIF 2.2 or higher)
PC/MAC Software	NMS, Internet Explorer/-
Mobile applications	MEye (iPhone, Android), MEyePro (iPhone, Android)
Number of Simultaneous Connections	Up to 4 clients
Bandwidth	20Mb/s in total to all client workstations
PTZ
PTZ Functions	Pan/tilt/zoom, preset commands*
AUXILIARY INTERFACES
USB Ports	2xUSB 2.0,
OPERATINGSYSTEM
Operatingsystem	Linux
Operation Mode	Triplex
OSD	Languages: Polish, English, Russian, others
Control	PC mouse (in-set included), network
System Diagnostic	Automatic control of: HDDs, network, camera connection loss
Security	Password protection, IP filtering, MAC filtering
INSTALLATION PARAMETERS
Dimensions (mm)	260(W)x45(H)x235(D)
Weight	1kg
Power Supply	200 ~ 240VAC
Power Consumption	30W
Operating Temperature	0°C ~ 50°C

* Function depends on communication protocol, for details please check full user manual.
** Available with dual streaming mode.
*** List of compatible HDD models and maximum of their capacities is available in section DOWNLOADABLE FILES.
